G104STN01.0 G104SN02 V.2 G104VN01 V.1 G104SN03 V.5 Original stock test shows normal
100% Japan Original Tension Detector LX-005TD LX-015TD LX-030TD LX-050TD LX-100TD LX-200TD
- Delivered today (order Mon-Fri before 12:00, delivery between 17:00 and 22:00)
- Including shipping costs, sent by Rare Good Store
- Pick up at a Rare Good Store collection point is possible
- 30 days to change your mind and free returns
- Day and night customer service
Description
- Hign-concerned Chemical: None
- Material: Aluminium-copper Alloy
- is_customized: No
- Model Number: LX-005TD LX-015TD LX-030TD LX-050TD LX-100TD LX-200TD
- Type: Power Tool Parts
- Origin: Mainland China
- Use: Commercial Manufacture
- Appicable load direction: Compression,tension in two directions
- Installation: Ground-mounted,wall-mount,ceiling mount
100% Japan Original Mitsubishi Tension Detector LX-005TD LX-015TD LX-030TD LX-050TD
Features
1.Compared to older models, hysteresis, temperature changes, changes over time are reduced by 50% or more.
2 .The width dimension of 48mm (LX-050TD mode), the use of the device can be miniaturized.
3.Can be installed in the wall, can also be installed on the ground, In addition, the use of the connection of the connector, each mounting seat frame with a mounting plate.
Specifications
|
Item |
Specification |
|||||||
|
Mode |
Non-explosion-proof |
LX-005TD |
LX-015TD |
LX-030TD |
LX-050TD |
LX-100TD |
LX-200TD |
|
|
Explosion-proof |
LX-005TD-928 |
LX-015TD-928 |
LX-030TD-928 |
LX-050TD-928 |
LX-100TD-928 |
LX-200TD-928 |
||
|
Rated load（N) |
50 |
150 |
300 |
500 |
1000 |
2000 |
||
|
Applicable load direction |
Compression, tension in two directions |
|||||||
|
Installation |
Ground-mounted, wall-mount, ceiling mount |
|||||||
|
Cable specifications |
Non-explosion-proof:7m×φ7(annex)、Explosion-proof：20 m×φ8(annex) |
|||||||
|
The main weight（kg) |
1.8 |
3 |
||||||
|
Conditions of Use |
Ambient temperature：-5~+60℃ Vibration：Below 2m/s⊃2; |
|||||||
|
Dimensions |
picture 1 |
picture 2 |
||||||
|
Applicable bearings |
UCP201-204 By using the optional LX-030PLT,can also be applied UCP205 |
UCP201-204 By using the optional LX100PLT, Can also be applied UCP205,206 |
||||||
