G104STN01.0 G104SN02 V.2 G104VN01 V.1 G104SN03 V.5 Original stock test shows normal
5MP 50fps Global Shutter USB Camera 10x Zoom CS Varifocus Lens High Speed 60fps 1080P Industrial UVC Plug Play PC Webcam
- Delivered today (order Mon-Fri before 12:00, delivery between 17:00 and 22:00)
- Including shipping costs, sent by Rare Good Store
- Pick up at a Rare Good Store collection point is possible
- 30 days to change your mind and free returns
- Day and night customer service
Description
- Hign-concerned Chemical: None
- Package: Yes
- Memory Card Type: None
- Model Number: ELP-USBGS5MP01-MFV(5-50)
- Sensor Technology: CMOS
- High Definition Support: 1080P (Full-HD)
- Brand Name: ELP
- Origin: Mainland China
- Type: Mini
- Certification: CE,FCC
- Max resolution: 2592×1944
- Sensor: 1/2.5 OmniVision OX05B1S
- Lens: 2.8-12/3.6-10/5-50mm varifocus lens
- Cable: 3m (2/3/5m optional)
- Video Compression Format: MJPEG
- Shutter Type: Global shutter
- High frame rate frame: 2592×1944 @ 50fps/ 2592×1440 @ 60fps
- Board size: 38*38mm
- OS: Windows Linux Android Mac
5MP 50fps Global Shutter USB Camera 10x Zoom CS Varifocus Lens High Speed 60fps 1080P Industrial UVC Plug Play PC Webcam
Package includes:
1) 1PC 5MP global shutter color usb camera
2) 1PC 3m usb cable
* Global Shutter Sensor – OmniVision OX05B1S Color Global Shutter Sensor without Distortion or Lag
* 60FPS High Frame Rates – 2592×1944 5MP 50FPS, 2592×1440 60FPS,1920×1080 60FPS
* 5MP Full HD Resolution – 5MP Max Resolution 2592X1944 for High quality Still Picture & Video
* 2.8-12mm/3.6-10mm/5-50mm varifocus CS lens Optional
* Mini Compact PCB Board Size – Suitable for Many Embedded Application
* Adjustable Features – many parameters adjustable, allows you customize the camera’s performance according to your needs.
* Ease of Use -Free driver,simply connect to a USB port then Plug & Play,No need additional hardware, driver or complex setup processes
* Easy Integration & High Compatibility- Support Android, Windows, Linux. Mac OS etc. compatible with a wide range of applications and platforms, including video chat software, video recording software and social media platforms
* Wide Applications – Automatic Number Plate Recognition (ANPR), Autonomous Mobile Robots (AMR), Gesture Recognition, Robotic Vision, Drones, Bar code Scanner, Factory Automation, Conveyor Monitoring Cameras, and Traffic Monitoring Systems etc.
|
Models (with fisheye Lens) |
ELP-USBGS5MP01-MFV(2.8-12) (2.8-12mm varifocus lens) ELP-USBGS5MP01-MFV(3.6-10) (3.6-10mm varifocus lens) ELP-USBGS5MP01-MFV(5-50) (5-50mm varifocus lens) |
|
Sensor |
1/2.5”OmniVision OX05B1S (Global Shutter) |
|
Max Resolution(Default) |
2592 (H) *1944 (V) |
|
Sensor Size |
1/2.5 inch (4:3) |
|
Image Array Area |
5737μmx4312μm |
|
Pixel Size |
2.2μmx 2.2μm |
|
Compression Format |
MJPEG / YUV2 (YUYV) |
|
Resolution & Frame Rate |
2592×1944 @ 50fps MJPEG/ 2592×1440 @ 60fps MJPEG 2560×1440 @ 60fps MJPEG/ 2304×1296 @ 60fps MJPEG 2048×1536 @ 50fps MJPEG/ 1920×1080 @ 60fps MJPEG 1600×1200 @ 50fps MJPEG/1600×900 @ 60fps MJPEG 1280×960 @ 50fps MJPEG/1280×720 @ 60fps MJPEG 1024×768 @ 50fps MJPEG/ 1024×576 @ 60fps MJPEG 960×720 @ 50fps MJPEG/ 960×540 @ 60fps MJPEG 800×600@ 50fps MJPEG/800×450 @ 60fps MJPEG 848×480 @ 60fps MJPEG/640×480 @ 50fps MJPEG 640×360 @ 60fps MJPEG/ |
|
Surface Mount Technology |
SMT |
|
Focus |
FixedFocus |
|
Central Definition |
1000LW/PH (Center) |
|
S/N Ratio |
38dB |
|
Dynamic Range |
72dB |
|
Sensitivity |
1.4V/lux-sec@550nm |
|
Min Illumination |
0.1Lux |
|
Shutter |
Global Shutter |
|
Interface |
USB2.0 High Speed |
|
AEC/AWB/AGC |
Support |
|
Adjustable Parameters |
Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White balance, Backlight Compensation, Exposure |
|
Lens Parameters |
2.8-12mm/3.6-10mm/5-50mm varifocus CS lens Optional |
|
LED board power connector |
Support 2P-2.0mm socket |
|
Power Supply |
USB BUS POWER 4P-2.0mm socket |
|
Operating Voltage |
DC 5V |
|
Working Current |
180mA- 230mA |
|
Dimension |
38mmx 38mm |
|
Working Temperature |
0°C to 60°C |
|
Storage Temperature |
-20°C to 80°C |
|
USB Cable |
3M (2M/3M/5M … Optional ) |
|
Operating System Request |
WinXP/Vista/Win7/Win8/Win9/Win10/Win11 etc. Linux with UVC (above linux-2.6.26) MACOS X 10.4.8 or later, Android 4.0 or above with UVC |
Car and ship control, electronic equipment, oil field equipment, industrial equipment, remote site
monitoring, environmental monitoring, etc.
used for all kinds of machine as below:
machinery equipment, all-in-one machine, POS equipment, STB, smart box TV BOX, advisement player,
LED display, automatic vending machine, safety box, notebook, video door phone, MID, Tablet external,
evaluator, Medical Equipment, on-the-spot law enforcement, door bell and button system, cat-eye system,
simple security system, teaching system, Interactive system, automobile data recorder. Project video capture,
credit card machine, attendance machine, Voting system, High speed video shooting Device, exam system,
Driving learning system, Industrial camera, biological microscope, box inside surveillance, micro HD surveillance,
endoscope, Medical auxiliary equipment, etc.
High Frame Rates – 2592×1944 5MP 50FPS, 2592×1440 60FPS,1920×1080 60FPS
It is suitable for applications with short exposure times (such as<500us), can shoot high-speed moving objects in crisp sharp images, avoid partial exposure, skew, and wobble
2.8-12mm/3.6-10mm/5-50mm varifocus CS lens Optional
For RASPBERRY PI & Android development Board
* It can work with already preinstalled camera software instead of built-in camera.
* Support Android development board,Raspberry Pi development board,Jetson Nano,etc.
For PC:
* Support windows,linux,mac,Android,raspberry Pi, ubuntu…
* Very easy to use,UVC compliant,free driver,just plug and play.
Our USB Camera include VGA 640X480,1MP,1.3MP,2MP,5MP and 8MP resolution
